MSI GeForce RTX 5070 VENTUS 12G OC
MSIRs0
Chat on WhatsApp
Overview
The MSI GeForce RTX 5070 VENTUS 12G OC is a high‑performance dual‑slot graphics card built on NVIDIA’s Blackwell architecture, featuring 6,144 CUDA cores and 12 GB of 28 Gbps GDDR7 memory on a 192‑bit bus. Factory‑overclocked to boost clocks around 2,557 MHz in Extreme Performance mode, it delivers fluid frame rates in 1440p and ultra‑wide 4K gaming. Its dual TORX Fan 5.0 cooling system, combined with precision‑machined heat pipes, a nickel‑plated copper baseplate, and a reinforced metal backplate, ensures efficient heat dissipation, while Zero Frozr technology stops the fans under light loads for near‑silent idling. Connectivity includes three DisplayPort 2.1b outputs and one HDMI 2.1b port, supporting high‑refresh‑rate or 8K displays, and its 250 W power draw is handled via a single 16‑pin 12V‑2×6 connector (with a 650 W PSU recommended). Full support for real‑time ray tracing, DLSS 4, NVIDIA Reflex, and G‑SYNC makes it a compelling choice for gamers and creators seeking energy‑efficient, top‑tier performance.
MSI GeForce RTX 5070 VENTUS 12G OC
The MSI GeForce RTX 5070 12G Ventus OC is built around NVIDIA’s Blackwell‑based GB205 GPU, featuring 6,144 CUDA cores and 12 GB of ultra‑fast GDDR7 memory clocked at 28 Gbps across a 192‑bit bus—delivering approximately 672 GB/s of bandwidth for high‑fidelity gaming at 1440p and capable 4K performance when paired with AI‑driven upscaling. Factory‑tuned to boost clock speeds in the mid‑2.5 GHz range, it leverages NVIDIA’s DLSS 4 and Reflex technologies for enhanced frame rates and low‑latency responsiveness. The Ventus cooling solution employs dual Torx Fan 5.0 blades, precision‑machined heat pipes, and a nickel‑plated copper baseplate to efficiently dissipate heat into a large aluminum heatsink, while a reinforced metal backplate adds structural rigidity and passive cooling. MSI’s Zero Frozr fan‑stop feature halts fan operation under light loads for whisper‑quiet idling, spinning them up only during demanding sessions. Despite a 250 W TDP, the card maintains a compact dual‑slot, sub‑250 mm footprint and draws power through a single 16‑pin PCIe 5.0 connector (or two 8‑pin adapters), making it an ideal fit for both mid‑tower and small‑form‑factor systems. Connectivity includes three DisplayPort 2.1b ports and one HDMI 2.1b port, supporting high‑refresh‑rate ultrawide monitors, VR headsets, and up to 8K displays, while support for PCIe 5.0, Resizable BAR, NVIDIA Studio, and RTX Broadcast ensures versatility for both gaming and creative workflows.
